Switch D-Link GO-SW-8G 8 Puertos/ RJ-45 10/100/1000

Extiende la red de tu casa con Switch D-Link GO-SW-8G. Conectándolo al router puedes añadir hasta 7 puertos más para 7 dispositivos de red con conexión Fast Ethernet. Puedes conectar dispositivos como una videoconsola, una impresora, servidor de impresión, NAS o una cámara IP.
Estándares
IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twistedpair copper)
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.3az Energy-Efficient Ethernet (EEE)
Protocolo:
CSMA/CD
Tasas de transferencia:
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit Ethernet: 2000 Mbps (full duplex)
Topología:Estrella
Cables de red
10BASE-T:
UTP CAT 3, 4, 5/5e (100 m max.)
EIA/TIA-586 100-ohm STP (100 m max.)
100BASE-TX, 1000BASE-T:
UTP CAT 5/5e (100 m max.)
EIA/TIA-568 100-ohm STP (100 m max.)
Media Interface Exchange:
Auto MDI/MDIX en todos los puertos
Indicadores LED
Por puerto: Link/Activity/Speed
Por dispositivo: Power
Método de transmisión:
Store-and-forward
Tabla de direcciones MAC:
2K
Aprendizaje de direcciones MAC:
Actualización automática
Filtrado de paquetes / Tasas de reenvío
Ethernet: 14,880 pps por puerto
Fast Ethernet: 148,800 pps por puerto
Gigabit Ethernet: 1,488,000 pps por puerto
RAM Buffer:
128KB per device
Jumbo Frames:
9,216 Bytes
DC Input:
External 5 V/1 A Level «V» Power Adapter
Consumo
DC input: 3.06 watts
AC input: 3.9 watts
MTBF:
412,433 horas
Temperatura
Funcionamiento: 32 to 104 ºF (0 to 40 ºC)
Almacenamiento: 14 to 158 ºF (-10 to 70 ºC)
Humedad
Funcionamiento: 10% to 90% RH non-condensing
Almacenamiento: 5% to 90% RH non-condensing
Dimensiones:128 x 68.5 x 25.4 mm
Peso:195 gr
Certificaciones
FCC Class B
ICES-003 Class B
CE Class B
C-Tick Class B
VCCI Class B
cUL/UL
CCC
Anatel
LVD
